Quick Details

  • Condition: New
  • CNC or Not: CNC
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: PHILICAM
  • Model Number: FLDM1530
  • Voltage: 380V/220v
  • Power(W): 3/4.5/6/KW
  • Dimension(L*W*H): 1500x3000x200mm
  • Weight: 1200KG
  • Certification: CE ISO FDA
  • Warranty: 1.5 Years
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Type:: Wood Cnc Router
  • Spindle Speed:: 0-24000RPM
  • Max. Working Speed:: 0-32000mm/min
  • Table Size:: 1500mm*3000mm
  • Software:: Type3 software, Wentai software, Artcam software
  • Operating System:: DSP System
  • Max. Consume power:: 6.5Kw
  • working table: vacuum working table
  • instudry: wooden machinery
  • transmission: XY GEear transmission,Z ball screw

Packaging & Delivery

Packaging Details plywood case
Delivery Time 15DAYS

china wood cnc router with vacuum working table FLDM1530



Application of  Wood CNC Router :



1.Wood working :Solid wave board process,door of cabinet,wooden door,artistic wooden door ,no-paint door,avoid wind,process of the artistic window,shoes cleaning machine,the cabinet of the playing machine and the board,mahjong table,computer table and the assistant process of the household effects

2.Advertising:Advertising board,Label design,Acrylic cutting,model, of the multi material decoration products.



3.Model industry:It can engrave on the steal materials such as copper, aluminum ,iron etc and  non-mental materials such as man-made marble, sand, plastic board PVC materials, wood board etc.



4.Other field:It can engrave many image, embossment,It is widely used in artistic industry.



Features of Wood Cnc Router :



1.With hard steel structure, fit for hard wood working, like cutting and engraving on rosewood for furniture, indoor decoration.



2.With the Vacuum holding way and dust collector, the machine is qualified for mass-producing of furniture.



3.The machine’s body is strong, rigid, high precision, reliable and durable.



4.Imported high precision ball screw gap, smooth movement, to ensure that the machine tools high-precision.



5.Well known domestic brands of water cooling brushless spindle, low noise, strong cutting ability, to ensure the long time working.



6.High-performance driven motor to ensure that the machine high speed and accuracy.



7.Designer perfectly, select the best machine accessories, to minimize the failure rate preferred.





Details of  Wood CNC Router :



Parameters of Cnc Router Wood :



No.

Description

Parameter

1

X,Y,Z Working Area

1500*3000mm

2

Table Size

1740×3540mm

3

X,Y,Z Traveling Positioning AccuraIT

±0.03/300mm

4

X,Y,Z repositioning Positioning AccuraIT

±0.05mm

5

Lathe Structure

Welded Structure

6

X, Y Structure

Gear Wheel Transmission,

Shaft Linear Bearings

7

Z Structure

Ball Screw,

Shaft Linear Bearings

8

Max. Consume power

6.5Kw

9

Max. Speed

0-32000mm/min

10

Max. Working Speed

0-20000mm/min

11

Spindle Power Motor

3.0KW water-cooling spindle

12

Spindle Speed

0-24000RPM

13

Working Mode

leadshine stepper motor and driver

14

Working Voltage

AC220V/50/60Hz,1PH

(Option: 380V,3PH)

15

Command

G Code, *uoo, *mmg, *plt

16

Operating System

DSP control system (NK105)



17

Interface

USB

18

Flash Memory

32M

19

Collet

ER25

20

X,Y Working DelicaIT

<0.01mm

Samples of  CNC router 1325 :

Our CE

Our factory

Our after sales

1.1.5 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.
2..Lifetime maintenance free of charge.
3.Free training course at our plant.

4..We will provide the consumable parts at an agency price when you need replacement.
5.24 hours on line service each day, free technical support.
6.24 service Tel: 86 13181737002
7.Machine has been adjusted before delivery.
8.Our engineers can be sent to your company to install or adjust if necessary

Please feel free to contact with me if you has any question.
